Drill Press Buying Guide: Types, Features, and Top Picks

A drill press is one of the most precise hole-making tools available to woodworkers and metalworkers alike. Unlike a handheld drill, a drill press holds the bit perfectly perpendicular to the worktable (or at a precisely set angle), maintains consistent speed regardless of feed pressure, and lets you set an exact depth stop for repeatable holes. For mortise-and-tenon work, shelf pin holes, hardware installation, and production drilling, a drill press is indispensable.

Modern drill presses range from compact benchtop units suitable for a small garage shop to heavy floor-standing machines used in professional cabinetmaking and metalworking. This guide walks through every key spec and feature so you can match the right machine to your actual work, then recommends the best models at each tier.

Types of Drill Presses

Benchtop Drill Press

A benchtop drill press mounts on your workbench or a dedicated stand. These machines are smaller, lighter, and more affordable than floor models, making them the right choice for hobbyists, small shop owners, and woodworkers who need occasional precision drilling without committing significant floor space or budget to the task.

Benchtop models typically offer swing sizes (see below) between 8 and 17 inches and motor sizes from 1/3 to 3/4 HP. Their tables are smaller, and they may have fewer speed settings than floor models, but for most woodworking applications they perform identically to their floor-standing counterparts.

Floor-Standing Drill Press

A floor-standing (or pedestal) drill press sits directly on the floor and offers greater height capacity, larger work tables, heavier construction, and — in larger models — more powerful motors. Floor models are preferred when you need to drill tall workpieces (chair legs, table legs, turned spindles), use large Forstner bits that require lower speeds and more torque, or plan to use your drill press as a dedicated spindle sander with a drum sanding attachment.

Floor models start at 15-inch swing and go up to 20 inches and beyond in industrial machines. For most serious hobbyists who use the drill press regularly, a 17-inch floor model offers the best balance of capability and value.

Key Specifications

Swing / Throat Depth

The swing is the specification you’ll see most prominently in a drill press description. It’s defined as twice the distance from the column to the center of the spindle. A 17-inch drill press can drill to the center of a 17-inch-wide workpiece. Note that this is a maximum, not an indication of the machine’s power or precision.

Throat depth is the actual distance from the column to the spindle center — half the swing. This is the limiting dimension when drilling holes close to the center of wide panels.

Quill Travel

Quill travel is the maximum distance the drill bit can travel downward in a single plunge — typically 2 to 4 inches on benchtop models and up to 6 inches on floor models. For woodworking operations like through-mortises in thick stock or deep Forstner bit holes, longer quill travel (3.5 inches or more) is valuable. Most hobby drilling doesn’t approach the quill travel limit, but it’s worth checking if your work includes deep holes.

Spindle Speed Range

Drill presses use belt-and-pulley systems to change speed — you physically move the belt to different pulley steps to change RPM. Most benchtop models offer 5 to 16 speed settings. The speed range matters more than the number of settings.

High speeds (2,500–3,600 RPM): Used for small drill bits in wood and small bits in soft metals
Mid speeds (700–2,500 RPM): General woodworking with standard twist bits and smaller Forstner bits
Low speeds (200–700 RPM): Large Forstner bits, hole saws, mortising chisels, drum sanding, and large bits in metal

A wider speed range gives you more flexibility. Look for a drill press that goes below 500 RPM for large bit work and above 3,000 RPM for small bit finish work.

Chuck Size and Taper

The chuck holds the drill bit. Most drill press chucks accept bits up to 1/2 inch in diameter (sometimes 5/8 inch on larger machines). Smaller budget chucks accept up to 3/8 inch — adequate for basic work but limiting for larger Forstner bits.

The chuck mounts to the spindle via a taper. Two standards are common:

JT33 (Jacob’s Taper #33): Found on most benchtop drill presses. Smaller and lighter, adequate for woodworking.
MT2 (Morse Taper #2): Found on floor models and heavier machines. Provides a more secure mechanical connection for heavy-duty drilling.

Either taper is fine for woodworking. MT2 is preferable for metalworking or production use where heavy feed pressure is common.

Table Size and Tilting

The drill press table (also called the worktable) should be large enough to support your workpieces. Most benchtop models have tables in the range of 9 x 9 to 14 x 14 inches. Tilting tables allow you to drill holes at angles — most tilt 45 degrees in both directions, which is useful for angled joinery and decorative work.

Look for a table with a center slot or T-slot that accepts clamps or a fence. Being able to clamp your workpiece to the table is essential for safety and accuracy. Drilling without clamping allows the workpiece to spin with the bit — a dangerous situation.

Features Worth Paying For

Laser Guide: A laser line or crosshair pattern projected onto the workpiece shows exactly where the bit will contact the material. Useful for lining up holes without a center punch, though any quality punch mark will do the job equally well. Nice to have, not essential.

LED Work Light: Illuminates the work area, especially useful when drilling dark materials or when shop lighting isn’t directly over the drill press. Common on mid-range and better models.

Depth Stop: An adjustable stop limits quill travel so you can drill to a consistent depth repeatedly without measuring each time. This is essential for shelf pin holes, cabinet hardware installation, and any production drilling. All quality drill presses include a depth stop; make sure it’s easy to set and holds its position firmly.

Digital Depth Readout: Some higher-end models include a digital display showing plunge depth. More precise than the analog stop scale, and useful for close-tolerance work.

Adjustable Table Height: The table should slide up and down the column and lock firmly at any height. This is standard, but the locking mechanism varies — a rack-and-pinion system is much easier to use than a simple clamp-and-slide design, especially when positioning the table under a large workpiece.

Best Drill Presses for 2026

WEN 4214 — Best Budget Benchtop Drill Press

The WEN 4214 is a 12-inch swing benchtop drill press that delivers reliable performance at an approachable price. It runs a 3.2-amp motor with 12 spindle speeds ranging from 580 to 3,200 RPM. The 1/2-inch chuck accepts a wide range of bit sizes, and the table tilts 45 degrees in both directions. An onboard laser guide and LED work light round out the features.

Build quality is in line with the price — the table is a modest size, and the depth stop scale is basic — but for a woodworker who needs occasional precision drilling and doesn’t want to spend $400+, the WEN 4214 is a competent entry point.

Swing: 12 inches
Motor: 3.2 amps
Speeds: 12 (580–3,200 RPM)
Chuck: 1/2 inch, JT33
Best for: Beginners, budget shops, light woodworking use

JET JDP-17 — Best Mid-Range Floor-Standing Drill Press

The JET JDP-17 is a 17-inch floor-standing drill press that hits the sweet spot between capability and cost for serious hobbyists and semi-professional woodworkers. It features a 3/4 HP induction motor, 16 spindle speeds from 200 to 3,630 RPM, and a 6-5/8-inch quill travel. The work table is large (14 x 14 inches), tilts 45 degrees, and features a T-slot for attaching fences and clamps.

JET’s build quality is well above budget brands — the table rack-and-pinion height adjustment is smooth, the column is solid and doesn’t flex, and the fit and finish are respectable. For a woodworker who wants a floor model that will last decades and handle everything from small twist bits to 3-inch Forstner bits, the JDP-17 is an excellent investment.

Swing: 17 inches
Motor: 3/4 HP
Speeds: 16 (200–3,630 RPM)
Chuck: 5/8 inch, MT2
Best for: Serious hobbyists, semi-professional shops, regular use

JET JDP-17 Drill Press on Amazon

Delta 18-900L — Best for Laser and Lighting Features

The Delta 18-900L is an 18-inch floor-standing drill press with a focus on precision and user-friendly features. It includes an adjustable laser and LED light system that is more refined and accurate than most budget laser guides. The 3/4 HP motor drives 16 speeds from 170 to 3,000 RPM, and the cast iron table (16 x 15 inches) is one of the largest in this class. The depth stop is easy to set and holds firmly.

Delta’s build quality is solid, and the larger table is genuinely useful for panel work and longer boards. If you want laser guidance that actually works well and a generous table size, the Delta 18-900L is worth the price premium over the JET.

Swing: 18 inches
Motor: 3/4 HP
Speeds: 16 (170–3,000 RPM)
Chuck: 5/8 inch
Best for: Precision work, users who value laser accuracy, wider workpieces

Powermatic PM2800B — Best Premium Drill Press

The Powermatic PM2800B is the top-of-the-range choice for woodworkers who want the best. Its 1 HP motor with variable speed control (achieved electronically rather than belt changes) allows you to dial in exact RPM with a knob — no belt moves required. The digital depth display is accurate to 0.001 inch. The table is large, smooth, and precisely machined.

The PM2800B’s variable speed system is a genuine upgrade over belt-change designs — especially when you’re switching between different bit sizes and materials throughout the day. No more pausing to open the belt cover and shift the belt. For production woodworking shops where the drill press runs all day, this feature alone justifies the price difference.

Swing: 20 inches
Motor: 1 HP, variable speed (250–3,000 RPM)
Chuck: 5/8 inch, MT2
Best for: Professional shops, production drilling, discerning hobbyists

Drill Press Accessories Worth Having

Fence: A fence clamped parallel to the quill ensures consistent hole placement on repeat drilling operations. JET and Delta sell purpose-built fences for their presses; universal fences work on most tables.

Drum Sanding Attachment: A drum sander mounted in the drill press chuck converts it into a spindle sander for smoothing curved cuts. This is one of the best secondary uses for a drill press.

Mortising Attachment: A hollow-chisel mortising attachment clamps to the quill and cuts square mortises for traditional joinery. Requires low speed and a firm workpiece clamp.

Drill Press Vise: For metalworking or small workpieces, a drill press vise clamps to the table and holds the workpiece securely without manual clamping.

Safety Tips

Always clamp your workpiece. A bit catching in an unclamped workpiece can spin it violently.
Remove the chuck key before starting the press. Modern chucks have self-ejecting keys, but always double-check.
Lower the speed for large bits and hard materials. A 2-inch Forstner bit at 3,600 RPM is dangerous; use 200 to 400 RPM.
Keep the quill locked when not in use. This prevents the spindle from dropping unexpectedly when changing bits.
